DT-BD5-8A Rebar Bending Machine

  • Description
    DT-BD5-8A  Rebar AUTO Bending Machine

    1.This machine is automaticly to operate. Encoder measure the angle and servo motor measure the length
    2. Have 32 set of shaping model, It is easy to adjust the angle, length from touch panel
    3. Shortest length : 100 mm
    4. High efficiency.Average daily machine quantity:8000 bars per man.
    5. High accuracy.Lower down the labor cost.
  • Specification

    Diameter for the bending steel

    SD3#-8#       D10mm-D25mm    (SD280/420)

    Number of bending steel in one time

     Qty975321
     sizeD10D13D16D19D22D25

    Maximum bending length

    0∘~ 180∘

    Bending angle

    Clockwise 3sets (Left side)
    Counterclockwise 2set (Right side)

    Bending direction

    55∘/ 1 sec    55∘/ 1 second

    Bending speed

    2.25KW x 5(Bend) 1.5KW x 1(Air compressor)

    1.5KW x 1(conveyer)

    Horse power of motor

    3Phase 220V  60HZ AIR  6kg/cm²

    Power supply

    10300 X 2100 X 1350

    Machine size (LXWXH)

    5450kg

    Maximum bending length



    A

    B

    C

    D

    E

    F

    R

    D10-D32

    110

    330

    150

    110

    330

    130

    Ø45

    Minimum bending length



    A

    B

    C

    D

    E

    F

    R

    D10-D32

    12M

    12M

    ≦A

    12M

    12M

    ≦D

    Ø104





    可彎8種圖形(轉逆90度)
